Product Details
＋
Cal-Royal's mission is to be the preeminent provider of superior construction services by consistently improving the quality of their products; to add value for their customers through innovation, foresight, integrity, and aggressive performance.
Features:
- Individual springs on each side to prevent lever sag, maintain reliability, and reduce maintenance.
- Meets the Buy American Act
- Meets ADA requirements specially designed for Barrier-Free application.
- Conforms with ANSI / BHMA A156.2, Series 4000, Grade 2 Requirements Exceeds 400,000 Cycles.
Specifications:
| Lock Function | Classroom |
| Usage | Medium Duty |
| Keyway | Schlage C Keyway |
| Handing | Non-Handed |
| Backset | 2-3/4" |
| Finish | US26D (626) Satin Chrome |
| ANSI/BHMA Standard | Meets or exceeds requirements of BHMA/ANSI A156.2 Series 4000, Grade 2 |
| Fire Rating | UL/cUL listed up to 3 Hours |
| Latch | 1/2” throw, deadlocking – 1-1/8" x 2-1/4" face |
| Strike | 4-7/8” x 1-1/4” ASA/ANSI strike with curved lip to meet ANSI A115.2 door frame preparation |
| Door Thickness | 1-3/8" to 1-3/4" |
