Product Description
-
2MP, 1/2.8" CMOS image sensor, low illuminance and high definition image
-
Outputs max. 2MP (1920 × 1080) @25/30 fps
-
H.265 codec, high compression rate, and ultra-low bit rate
-
Built-in IR LED, and the max. IR distance is 30 m
-
RoI, SMART H.264 /H.265 , flexible coding, applicable to various bandwidth and storage environments
-
Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking,applicable to various monitoring scenes
-
Abnormality detection: Motion detection, video tampering, network disconnection, IP conflict, illegal access
-
12V DC power supply
-
IP67 protection
-
Functions
-
Smart H.265 & Smart H.264
-
With advanced scene-adaptive rate control algorithm, Dahua smart encoding technology realizes the higher encoding efficiency than H.265 and H.264, provides high-quality video, and reduces the cost of storage and transmission
-
Smart Illumination
-
Dahua Smart Illumination technology can display image in the environment of low illuminance or completely dark environment
-
According to the distance of the targets, the camera adjusts Illuminations intensity automatically to display the details of the moving target
-
Motion Detection
-
When moving objects appear in the monitoring image, Dahua Motion Detection technology triggers alarm or records
-
Image Flip
-
For narrow and long scenes, Dahua image flip technology flips the im age by 90°/180°/270° to realize better surveillance in rotation mode
-
Cyber Security
-
Dahua network cameras employ a series of security technologies, including security authentication and authorization, access control protocols, trusted protection, encrypted transmission and encrypted storage
-
These technologies improve the camera's defense against external cyber threats and prevent malicious programs from compromising the device
-
Protection (IP67, Wide Voltage)
-
IP67: The camera passes a series of strict test on dust and soak
-
It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes
-
Wide voltage: The camera allows ±30% (for some power supplies) input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage
Product Specification
Brand |
Dahua |
||||
Product Type |
Network Camera |
||||
Model |
DH-IPC-HFW1230DS1-S5 |
||||
Series |
Lite |
||||
Camera | |||||
Image Sensor |
1/2.8" CMOS |
||||
Max. Resolution |
1920 (H) × 1080 (V) |
||||
ROM |
16 MB |
||||
RAM |
64 MB |
||||
Scanning System |
Progressive |
||||
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
||||
Min. Illumination |
0.01 [email protected] (Color,30 IRE) 0.001 [email protected] (B/W,30 IRE) 0 lux (Illuminator on) |
||||
S/N Ratio |
> 56 dB |
||||
Illumination Distance |
30 m (98.4 ft) (IR) |
||||
Illuminator On/Off Control |
Auto; manual |
||||
Illuminator Number |
1 (IR LED) |
||||
Pan/Tilt/Rotation Range |
Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360° |
||||
Lens | |||||
Lens Type |
Fixed-focal |
||||
Lens Mount |
M12 |
||||
Focal Length |
2.8 mm; 3.6 mm |
||||
Max. Aperture |
2.8 mm: F2.0 3.6 mm: F2.0 |
||||
Field of View |
2.8 mm: Horizontal: 84°; Vertical: 45°; Diagonal: 100° 3.6 mm: Horizontal: 102°; Vertical: 54°; Diagonal: 120° |
||||
Iris Control |
Fixed |
||||
Close Focus Distance |
2.8mm: 0.5 m (1.6 ft) 3.6mm: 0.8 m (2.6 ft) |
||||
DORI Distance |
Lens |
Detect |
Observe |
Recogniz |
Identify |
2.8 mm |
Dahua Entry IR Fixed-Focal Bullet Network Camera 2MP DH-IPC-HFW1230DS1-S5$ 83.82 $ 64.48 Please select combo product attributes
