Product Description
-
2MP, 1/2.7” CMOS image sensor, low illuminance, high image definition
-
Outputs max. 2MP (1920 × 1080) @25/30 fps
-
H.265 codec, high compression rate, ultra-low bit rate
-
Built-in IR LED, max. IR distance: 30 m
-
ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
-
Rotation mode, DWDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
-
Abnormality detection: Motion detection, video tampering, network disconnection, IP conflict, illegal access
-
12V DC/PoE power support
-
IP67 protection
-
Functions
-
Smart H.265 & Smart H.264
-
With advanced scene-adaptive rate control algorithm, Dahua smart encoding technology realizes the higher encoding efficiency than H.265 and H.264, provides high-quality video, and reduces the cost of storage and transmission
-
Smart IR
-
Dahua Smart IR technology can display image in the environment of low illuminance or completely dark environment
-
According to the distance of the targets, the camera adjusts IR LEDs intensity automatically to
-
display the details of the moving target
-
Motion Detection
-
When moving objects appear in the monitoring image, Dahua Motion Detection technology triggers alarm or records
-
Image Flip
-
For narrow and long scenes, Dahua image flip technology flips the image by 90°/270° to realize better surveillance in rotation mode
-
Protection (IP67, Wide Voltage)
-
IP67: The camera passes a series of strict test on dust and soak
-
It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes
-
Wide voltage: The camera allows ±30% (for some power supplies) input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage
Product Specification
|
Brand |
Dahua |
||||
|
Product Type |
Network Camera |
||||
|
Model |
DH-IPC-HFW1230SP-S4 |
||||
|
Series |
Lite |
||||
|
Camera |
|||||
|
Image Sensor |
1/2.7" 2Megapixel progressive CMOS |
||||
|
Effective Pixels |
1920 (H) × 1080 (V) |
||||
|
ROM |
16 MB |
||||
|
RAM |
64 MB |
||||
|
Scanning System |
Progressive |
||||
|
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100000 s |
||||
|
Min. Illumination |
0.01 Lux @F2.0 |
||||
|
IR Distance |
30 m (98.4 ft) |
||||
|
IR On/Off Control |
Auto/Manual |
||||
|
IR LEDs Number |
1 |
||||
|
Pan/Tilt/Rotation Range |
Horizontal: 0°–360° Vertical: 0°–90° Rotation: 0°–360° |
||||
|
Lens |
|||||
|
Lens Type |
Fixed-focal |
||||
|
Mount Type |
M12 |
||||
|
Focal Length |
2.8 mm 3.6 mm |
||||
|
Max. Aperture |
F2.0 F2.0 |
||||
|
Field Of View |
2.8 mm: Horizontal: 105° Vertical: 57° Diagonal: 125° 3.6 mm: Horizontal: 87° Vertical: 47° Diagonal: 104° |
||||
|
Iris Type |
Fixed aperture |
||||
|
Close Focus Distance |
2.8 mm: 0.5 m (1.6 ft) 3.6
$
