Product Description

• Max. 30fps@1080P

• HD and SD output switchable

• 3.6mm fixed lens (2.8mm, 6mm optional)

• Max. IR length 20m, Smart IR

• IP67, DC12V

• Functions

• 4 Signals over 1 Coaxial Cable

• HDCVI technology supports 4 signals to be transmitted over 1 coaxial cable simultaneously, i.e. video, audio, data and power. Dual-way data transmission allows the HDCVI camera to interact with the HCVR, such as sending control signal or triggering alarm. Moreover, HDCVI technology supports PoC for construction flexibility

• Audio input is available for some models of HDCVI cameras

• Long Distance Transmission

• HDCVI technology guarantees real-time transmission at long distance without any loss

• It supports up to 800m(1080P)/1200m(720P) transmission via coaxial cable, and up to 300m(1080P)/450m(720P) via UTP cable

• Actual results verified by real-scene testing in Dahua's test laboratory

• Simplicity

• HDCVI technology inherits the born feature of simplicity from traditional analog surveillance system, making itself a best choice for investment protection

• HDCVI system can seamlessly upgrade the traditional analog system without replacing existing coaxial cabling

• The plug and play approach enables HD video surveillance without the hassle of configuring a network

• Smart IR

• The camera is designed with microcrystalline LED IR illumination for best lowlight performance

• Smart IR is a technology to ensure brightness uniformity in B/W image under low illumination

• Dahua’s unique Smart IR adjusts to the intensity of camera's infrared LEDs to compensate for the
  distance of an object, and prevents IR LEDs from overexposing images as the object come closer to the camera

• Multi-formats

• The camera supports multiple video formats including HDCVI, CVBS and other two common HD analog formats in the market

• The four formats can be switched over through OSD menu or by PFM820(UTC controller)

• This feature makes the camera to be compatible with not only HCVRs but also most end users existing HD/SD DVRs

• Multi-language OSD

• OSD menu provides multiple image adjustments and function settings to meet the requirements of different monitoring scenes

• The OSD menu includes configurations such as backlight mode, day/night, white balance, privacy mask and motion detect

• The camera supports 11 languages for OSD menu, namely, Chinese, English, French, German, Spanish, Portuguese, Italian, Japanese, Korean, Russian and Polish

• Protection

• The camera's outstanding reliability is unsurpassed due to its rugged design

• The camera is protected against water and dust with IP67 ranking, making it suitable for indoor or outdoor environments

• With working temperature range of -40°C to 60°C (-40°F to 140°F), the camera is designed for extreme temperature environments

• Supporting ±30% input voltage tolerance, this camera suits even the most unstable power supply conditions. Its 4KV lightning rating provides protection against the camera and its structure from the effects of lightning

Product Specification

Brand	Dahua
Product Type	Bullet Camera
Model	DH-HAC-B1A21P
Series	Cooper
Camera
Image Sensor	1/2.7" CMOS
Effective Pixels	1280(H)×720(V), 1MP
Scanning System	Progressive
Electronic Shutter Speed	PAL: 1/25~1/100000s NTSC: 1/30~1/100000s
Minimum Illumination	0.04Lux/F2.4, 30IRE, 0Lux IR on
S/N Ratio	More than 65dB
IR Distance	Up to 20m (66feet)
IR On/Off Control	Auto / Manual
Lens
Lens Type	Fixed lens / Fixed iris
Mount Type	Board-in
Focal Length	2.8mm
Max Aperture	F2.4
Angle of View	H: 93° V: 48°
Focus Control	N/A
Close Focus Distance	800mm 31.50''
DORI Distance
Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively
	DORI Definition	Distance
Detect	25px/m (8px/ft)	2.8mm: 51m(167ft)
Observe	63px/m (19px/ft)	2.8mm: 20m(66ft)
