Name: Lockey - TB250 - Adjustable Hydraulic Gate Closer - (50-125 lbs)
SKU: 1278666

Product Details ＋

LK-TB250

Features

Adjustable hydraulic (nitrogen gas) controlled closing speed
Closes small and large gates from 50-125 lbs.
Installs on top/middle/bottom
Works with left and right hand gates
Mounts on opening side of gate
Pushes the gate closed
Mounting brackets and fitting bar included
Not compatible with gates less than 30 inches wide

Specifications

GATE DIMENSIONS	Weight: 50-125 lbs. - Width: 36-52"
FINISHES AVAILABLE	Black
MAX. OPENING ANGLE	100 Degrees
OPERATING TEMPERATURES	Min: 15 Degrees Fahrenheit* Max: 122 Degrees Fahrenheit*
TYPE OF GATE MATERIAL	Vinyl; Steel; Wood; Chain Link**
CLOSING / LATCH METHOD	Hydraulic / Nitrogen Gas
MATERIAL	Steel
FINISH	PVC Wrapped
HINGE ARRANGEMENTS	In-line or Offset
OPENING PRESSURE	3 - 7 lbs.
WARRANTY	1 Year

Note: To retain product warranty & restrict gate opening angle, a gate stop must be installed (not included).
*Operation of the closer in temperatures below or above the minimum and maximum operating temperatures may result in improper operation or complete failure of the closer.
**In order to be mounted on chain link, a TB950-LINX is required (not included).

Videos

How to Install TB250 Gate Closer

How to Install TB250 Gate Closer on Chain Link

Downloads

Return Policy: We do not accept returns on unsealed products. In order to return a defective item a support ticket is needed. To receive a ticket, please contact Lockey directly at 888.395.0163 or visit their support page .
