The Paramount™ series wall mounts provide versatile and multi-functional features. With PP730, extend the display up to 7.4" (188mm) or fully-retract it to just 2.75" (7mm) from the wall for an improved viewing angle. The Hook-and-Hang™ system offers easy, one-person installation of the display. One-Touch™ tilt technology offers ±15° vertical tilt movement for the ideal viewing angle. Integrated cable management protects, contains and conceals cables for a clean installation.
- Accommodates 75 x 75 or 100 x 100mm VESA® mounting patterns
- Extends 7.40” (188mm) from the wall
- Retracts to 2.75” (70mm) to save space
- One-Touch™ tilt mechanism offers ±15° of tilt angle adjustment
- ±5° of roll for post installation display leveling
- ±90° of pivot |Design is UL listed and tested to four times stated load capacity
- Hook-and-Hang™, one-person display installation
- Integrated cable management protects, contains and conceals cables for a clean, professional installation
- Mounts to wood stud, concrete, cinder or breeze block
Product Specifications
-
Minimum to Maximum Screen Size
10" to 29"
-
VESA Pattern
75 x 75 and 100 x 100
-
Mounting Pattern
75 x 75 and 100 x 100mm (2.95 x 2.95, 3.94 x 3.94")
-
Weight Capacity
25lb (11.0kg)
-
Color
Black
-
Finish
High Gloss
-
Security Features
Non-Security Hardware| Tilt
-
Swivel Yaw
90 / -90
-
Roll
5 /-5
-
Distance from Wall
2.36 - 7.01" (60 - 178mm)
-
Product Dimensions
8.13 x 5.50 x 2.36 - 7.01" (207 x 140 x 60 - 178mm)
Package Specifications
-
Shipping Weight
2.65lb (1kg)
-
Ship Dimensions
7.28 x 2.76 x 10.39" (184.9 x 70.1 x 263.9mm)
