Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Accessory Type | Magnetic Lock |
| Actuator Color | Grey |
| Alternate Mfr Part Number | EMP50-24V-DC ; 7393223 |
| Current Rating | 350 mA |
| Diameter | 1.969" (50mm) mm |
| Dimensions | 50 (Dia.) x 94 mm |
| Finish | Bright Nickel Plated with Machined Face |
| For Use With | Machine Mechanisms, Door/Guard, Locking & Remote Hold/Release Requirements |
| Force | 500 N |
| IP Rating | IP54 |
| Length | 3.7" (94mm) |
| Shop By | Factory Choice |
| Special Features | 3 Year Warranty |
| Supply Voltage | 24 VDC |
| Type | Round Electromagnet |
| UPC Code | 5056112109396 |
| Warranty | 3 Year Warranty |
| Width | 2.480" (63mm) |
Overview
Energise to Release
These RS electro-permanent magnets provide a holding force when de-energised and release when pulsed.
Typical applications include: machine mechanisms, door/guard locking and remote hold / release requirements.
Optimum performance when used with RS armature plates (available separately): please see stock no
Energise to hold version available on example
12 and 24 vdc versions have a 2 pole connector
12 and 24 vdc versions are IP20 rated
240 vac versions have a Din 43650 connector
240 vac versions are IP54 rated
